TATA Drive's Bearing Heat Insulation Fan offers 1.5-75kW power, 5000-80,000m³/h air volume, and -20℃-400℃ working temp. Heat-insulated bearings, heat-resistant steel build, ideal for metallurgy/chemical high-temperature ventilation.
| Model | Frequency | Rated Power | Rated voltage | Rated current | Max. flow | Max. pressure | Max. vacuum | Noise | Duct caliber | G.W | ||
| (HZ) | (KW) | (V) | (A) | (m³/h) | (Kpa) | (Kpa) | (db) | (mm) | (KG) | |||
| HG210-30ALD | 50 | 0.3 | 220-240V | 1.7 | 76 | 8 | -6.5 | <53 | 40 | 14 | ||
| 60 | 0.35 | 220-240V | 2.0 | 93 | 10 | -7.5 | <56 | 40 | 14 | |||
| HG210-30ALS | 50 | 0.3 | 200-240△ | 345-415Y | 2.6△ | 1.5Y | 76 | 8 | -6.5 | <53 | 40 | 14 |
| 60 | 0.35 | 220-275△ | 380-480Y | 2.6△ | 1.5Y | 93 | 10 | -9.5 | <56 | 40 | 14 | |
| HG210-37ALD | 50 | 0.37 | 220-240V | 2.1 | 76 | 10 | -9 | <53 | 40 | 15 | ||
| 60 | 0.42 | 220-240V | 2.4 | 93 | 12 | -10 | <56 | 40 | 15 | |||
| HG210-37ALS | 50 | 0.37 | 200-240△ | 345-415Y | 2.6△ | 1.5Y | 76 | 10 | -9 | <53 | 40 | 14 |
| 60 | 0.42 | 220-275△ | 380-480Y | 2.6△ | 1.5Y | 93 | 12 | -11.5 | <56 | 40 | 14 | |
| HG310-55ALD | 50 | 0.55 | 220-240V | 3.2 | 90 | 12 | -11 | <57 | 40 | 17 | ||
| 60 | 0.62 | 220-240V | 3.6 | 105 | 12 | -11 | <60 | 40 | 17 | |||
| HG310-55ALS | 50 | 0.55 | 200-240△ | 345-415Y | 2.8△ | 1.6Y | 95 | 12 | -11 | <57 | 40 | 16 |
| 60 | 0.62 | 220-275△ | 380-480Y | 3.0△ | 1.7Y | 114 | 12 | -11 | <60 | 40 | 16 | |
| HG410-75ALD | 50 | 0.75 | 220-240V | 4.3 | 138 | 18 | -17 | <63 | 50 | 22 | ||
| 60 | 0.83 | 220-240V | 4.7 | 166 | 19 | -18 | <64 | 50 | 22 | |||
| HG410-75ALS | 50 | 0.75 | 200-240△ | 345-415Y | 3.8△ | 2.2Y | 138 | 18 | -17 | <63 | 50 | 21 |
| 60 | 0.83 | 220-275△ | 380-480Y | 3.75△ | 2.15Y | 166 | 19 | -19 | <64 | 50 | 21 | |
| HG510-11BLD | 50 | 1.1 | 220-240V | 4.9 | 200 | 21 | -19 | <64 | 60 | 29 | ||
| 60 | 1.25 | 220-240V | 5.5 | 242 | 20 | -19 | <70 | 60 | 29 | |||
| HG510-11BLS | 50 | 1.1 | 200-240△ | 345-415Y | 4.9△ | 2.8Y | 200 | 21 | -19 | <64 | 60 | 28 |
| 60 | 1.25 | 220-275△ | 380-480Y | 5.2△ | 3.2Y | 242 | 20 | -19 | <70 | 60 | 28 | |
| HG510-15BLD | 50 | 1.5 | 220-240V | 8.6 | 200 | 24 | -22 | <64 | 60 | 30 | ||
| 60 | 1.8 | 220-240V | 10.0 | 242 | 26 | -23 | <70 | 60 | 30 | |||
| HG510-15BLS | 50 | 1.5 | 200-240△ | 345-415Y | 6.2△ | 3.6Y | 200 | 24 | -22 | <64 | 60 | 29 |
| 60 | 1.8 | 220-275△ | 380-480Y | 6.9△ | 4.0Y | 242 | 26 | -23 | <70 | 60 | 29 | |
| HG710-22BLD | 50 | 2.2 | 220-240V | 12.5 | 247 | 33 | -30 | <69 | 60 | 40 | ||
| 60 | 2.55 | 220-240V | 15.0 | 276 | 35 | -33 | <72 | 60 | 40 | |||
| HG710-22BLS | 50 | 2.2 | 200-240△ | 345-415Y | 8.9△ | 5.2Y | 302 | 33 | -30 | <69 | 60 | 40 |
| 60 | 2.55 | 220-275△ | 380-480Y | 10.3△ | 6.5Y | 357 | 33 | -31 | <72 | 60 | 40 | |
| HG710-30BLS | 50 | 3.0 | 200-240△ | 345-415Y | 12.2△ | 7.3Y | 302 | 36 | -33 | <69 | 60 | 40 |
| 60 | 3.5 | 220-275△ | 380-480Y | 14.0△ | 8.1Y | 357 | 34 | -31 | <72 | 60 | 40 | |
| HG711-38BLS | 50 | 3.8 | 200-240△ | 345-415Y | 15.5△ | 9.0Y | 342 | 35 | -33 | <70 | 60 | 45 |
| 60 | 4.3 | 220-275△ | 380-480Y | 17.5△ | 10.2Y | 410 | 37 | -36 | <73 | 60 | 45 | |
| HG750-40BLS | 50 | 4.0 | 345-415△ | 600-720Y | 9.0△ | 5.2Y | 400 | 40 | -36 | <70 | 75 | 53 |
| 60 | 46 | 380-480△ | 660-720Y | 9.4△ | 5.2Y | 480 | 42 | -40 | <73 | 75 | 53 | |
| HG810-55BLS | 50 | 5.5 | 345-415△ | 600-720Y | 12.9△ | 7.4Y | 570 | 45 | -43 | <80 | 75 | 70 |
| 60 | 6.3 | 380-480△ | 660-720Y | 12.9△ | 7.45Y | 620 | 47 | -45 | <82 | 75 | 70 | |
| HG810-75BLS | 50 | 7.5 | 345-415△ | 600-720Y | 16.7△ | 9.6Y | 600 | 51 | -46 | <80 | 75 | 75 |
| 60 | 8.6 | 380-480△ | 660-720Y | 17.3△ | 10.0Y | 660 | 53 | -48 | <82 | 75 | 75 | |
Efficient Bearing Heat Insulation
Heat-insulating sleeve + air cooling isolates bearings from 400℃ high-temperature airflow.
High-Temperature Adaptability
Heat-resistant steel casing/impeller, stable operation in -20℃-400℃ harsh environments.
Stable & Low-Noise
Dynamic balancing + sealed bearings, <85dB noise, vibration <4.5mm/s for 24/7 use.
Energy-Saving & High-Efficiency
Airfoil impeller design, 70%-82% efficiency, reducing long-term high-temperature operation costs.
Durable & Easy Maintenance
Removable bearing seat, few wearing parts, simple lubrication/cleaning suffice.
The full range of products includes motors, input interfaces, output modules, installation forms, etc., which can be personalized designed and manufactured according to customer needs.
We offer multiple color schemes such as RAL7045 (gray), RAL9011 (black), RAL5015 (blue), RAL9003 (white), RAL3014 (purple), etc. Customers can choose the corresponding product color according to their different needs.
Our nameplate is made of stainless steel laser printing technology, which can be customized according to the different needs of customers, especially by adding a product QR code. Scanning the QR code can quickly access product information and sales service information.
Conventional packaging forms include cardboard boxes, pallets, and wooden boxes. We can also customize the outer box packaging according to customer needs.
