TATA Drive's HD Series has 0.18 - 188kW power, 11 - 1300N·m torque and 1 - 5 ratios. 94%-98% efficient, hexahedral housing fits multi-angle installation, suitable for food and metallurgy precision transmission.
| Gear ratio i | Input speed n1 r/min | Input speed n2 r/min | Enclosure Model | ||||||
| 09 | 11 | 14 | 17 | 21 | 24 | 28 | |||
| Allowed Input Power Pn (kW) | |||||||||
| 1 | 2000 | 2000 | 7.55 | 13.8 | 29.9 | 49.2 | 84 | 111 | 188 |
| 1500 | 1500 | 6 | 11 | 23.9 | 39.3 | 67.5 | 90.5 | 156 | |
| 1000 | 1000 | 4.3 | 7.85 | 17.2 | 28.8 | 50.5 | 68 | 115 | |
| 750 | 750 | 3.4 | 6.15 | 13.4 | 22.8 | 40.8 | 54.5 | 94.2 | |
| 1.5 | 2000 | 1333 | 5.45 | 9.7 | 16.8 | 33.9 | 70 | 92.5 | 124 |
| 1500 | 1000 | 4.3 | 7.75 | 13.5 | 27.2 | 56.5 | 75.5 | 103 | |
| 1000 | 667 | 3.05 | 5.45 | 9.7 | 19.6 | 41.2 | 55.5 | 75.5 | |
| 750 | 500 | 2.3 | 4.25 | 7.6 | 15.5 | 33 | 44.5 | 60.5 | |
| 2 | 2000 | 1000 | 4.2 | 7.95 | 14.1 | 26.2 | 52.4 | 71.5 | 107 |
| 1500 | 750 | 3.35 | 6.3 | 11.1 | 20.8 | 43.2 | 58.5 | 88 | |
| 1000 | 500 | 2.35 | 4.45 | 7.85 | 14.9 | 31.4 | 41.9 | 64.5 | |
| 750 | 375 | 1.8 | 3.45 | 6.2 | 11.6 | 25.2 | 33.8 | 51 | |
| 3 | 2000 | 667 | 2.85 | 5.6 | 10.1 | 18.2 | 34.9 | 52.4 | 73 |
| 1500 | 500 | 2.2 | 4.45 | 7.95 | 14.4 | 27.7 | 41.9 | 58.5 | |
| 1000 | 333 | 1.5 | 3.1 | 5.6 | 10.1 | 20 | 30.2 | 42.4 | |
| 750 | 250 | 1.2 | 2.4 | 4.4 | 7.8 | 15.7 | 23.6 | 33.5 | |
| 4 | 2000 | 500 | 2.15 | 3.75 | 6.8 | 10.5 | 23.3 | 37.7 | 47.6 |
| 1500 | 375 | 1.65 | 2.9 | 5.3 | 8.4 | 18.5 | 30.2 | 38.5 | |
| 1000 | 250 | 1.15 | 2 | 3.75 | 5.9 | 13.4 | 21.7 | 27.5 | |
| 750 | 188 | 0.87 | 1.55 | 2.95 | 4.55 | 10.4 | 17.1 | 21.7 | |
| 5 | 2000 | 400 | 1.4 | 2.95 | 5.05 | 8.05 | 15.9 | 28.9 | 39.4 |
| 1500 | 300 | 1.1 | 2.35 | 3.95 | 6.45 | 12.9 | 23.4 | 31.4 | |
| 1000 | 200 | 0.75 | 1.6 | 2.75 | 4.5 | 9 | 16.4 | 22.4 | |
| 750 | 150 | 0.58 | 1.25 | 2.1 | 3.45 | 6.95 | 13 | 17.7 | |
Ultra-High Transmission Efficiency:
Efficiency ranges from 94% to 98%. 20CrMnTi gears with grinding process and HRC58 - 62 hardness realize low-loss and smooth power transmission.
Flexible Multi-Angle Installation:
Hexahedral cast iron or aluminum housing. All six processed surfaces serve as mounting faces, adapting to diverse equipment spatial layouts.
Diversified Shaft & Connection Modes:
Supports solid/hollow shaft, spline and flange connections. It can add up to five drive shafts to meet multi-output transmission needs.
Dual Transmission Modes:
Achieves both speed reduction and acceleration. Reversible rotation adapts to high/low-speed transmission scenarios, flexibly matching different power input-output demands.
Strong Precision & Durability:
Grade 6 gear precision with low backlash. Equipped with imported seals and bearings, it runs stably for long in chemical and pharmaceutical harsh environments.
The full range of products includes motors, input interfaces, output modules, installation forms, etc., which can be personalized designed and manufactured according to customer needs.
We offer multiple color schemes such as RAL7045 (gray), RAL9011 (black), RAL5015 (blue), RAL9003 (white), RAL3014 (purple), etc. Customers can choose the corresponding product color according to their different needs.
Our nameplate is made of stainless steel laser printing technology, which can be customized according to the different needs of customers, especially by adding a product QR code. Scanning the QR code can quickly access product information and sales service information.
Conventional packaging forms include cardboard boxes, pallets, and wooden boxes. We can also customize the outer box packaging according to customer needs.
